ETON MW 12 – 300mm Performance Subwoofer
Meet the ETON MW 12 — part of ETON's new MW Performance Series, built for one purpose: serious bass. Full power, rock-hard punches, and deep low-end runs that hit you in the chest. Whether you're chasing extreme SPL or just want bass with real fun factor, the MW 12 delivers without compromise — all at a price point that makes it a no-brainer upgrade.
Engineered in Germany and built with proven cone materials, heavy-duty dual voice coils, and an extremely powerful ferrite magnet system — the MW 12 is ready to perform at the highest level in a sealed or ported enclosure.
🔊 Key Features
- 300mm (12") pressed, air-dried paper cone — optimised for tight, accurate bass response
- Additionally stitched long-throw surround — handles extreme excursion without failure
- Powder-coated reinforced die-cast aluminium basket — torsion-resistant and built to last
- Open basket construction — maximum heat dissipation for sustained performance
- Heavy-duty 2x2Ω dual voice coil (76mm diameter) — with built-in ventilation for cool running
- Extremely strong ferrite magnet — with large pole core bore and additional ventilation holes
- High-quality clamp terminals — secure, vibration-resistant connections
- Engineered in Germany
📋 Core Specifications
| Specification | Value |
|---|---|
| Impedance | 2 x 2 Ω (Dual Voice Coil) |
| Rated Power (RMS) | 900 W |
| Music Power | 1200 W |
| Sensitivity (1W/1m) | 86 dB |
| Outer Diameter | 326 mm |
| Cut-Out Diameter | 286 mm |
| Installation Depth | 175 mm |
| Voice Coil Diameter | 76 mm |
| Magnet Material | Ferrite |
| Xmax (Mechanical) | ±48.0 mm |
📐 Thiele-Small Parameters
| Parameter | Symbol | Value |
|---|---|---|
| Nominal Impedance | Zn | 2 x 2 Ω |
| DC Resistance | Re | 3.8 Ω |
| Resonance Frequency | fs | 31.6 Hz |
| Total Q Factor | Qts | 0.30 |
| Electrical Q Factor | Qes | 0.32 |
| Mechanical Q Factor | Qms | 5.54 |
| Equivalent Air Volume | Vas | 24.93 dm³ |
| Effective Piston Area | Sd | 491 cm² |
| Force Factor | Bl | 29.39 Tm |
| Voice Coil Inductance | Le | 3.10 mH |
| Total Moving Mass | Mmd | 348.12 g |
| Suspension Compliance | Cms | 0.07 mm/N |
| Mechanical Resistance | Rms | 11.94 kg/s |
💡 Why the ETON MW 12?
The MW 12's low Qts of 0.30 makes it a natural fit for ported enclosures where you want authority and extension down low. The massive ±48mm Xmax means this driver can move serious air without bottoming out — even at full rated power. Pair it with a quality monoblock amp in the 600–900W RMS range and you've got a system that'll absolutely thump.
Unlike budget subs that cut corners on the basket and magnet, ETON builds the MW 12 from the ground up with German engineering standards — proper materials, proper construction, proper sound.
📍 Garage Audio — Unit 3, 289-339 Morayfield Rd, Morayfield QLD 4506
📞 07 3093 1846 | Professional installation available in-store.
💬 DM us or call to discuss the right enclosure and amplifier match for your build.
